Toilet Paper Roll Making Machine

This hi-speed toilet paper roll machine efficiently makes good quality toilet rolls.

Features:

1. It is a slitting machine with perforation
2. Slitting blades could be adjusted to make kitchen rolls & industrial rolls
3. Electronic counter is provided which controls the number of sheets to be wounded over a given roll in this toilet roll making machine

Specification:

1. Semi-Automatic
2. Size : 81 cm working
3. Slitting distance : 99 mm
4. Cutter : 8 Rotary Cutter with Holder & Bottom
5. Perforation : Repeat on 110 mm above
6. Motor : 2 HP DC Motor with thyrister control drive
7. Maximum rewind : 200mm.
8. Speed : 1,500 to 1,800 Rolls/8 Hrs/100gm..
9. Unwind Station : One
10. Weight : 1100 Kgs/approx.
11. Man Power : One Operator & 1 Packer
12. Raw Material : 14 to 26 Gsm.(2ply)
13. Maximum Unwind Dia : 1200 mm Max.
14. Dimension : 80" L x 50" W x 40" H (Approx)
15. Counting : Auto cut Digitally Counting
16. Embossing :Attachment with mechanical Embossing ( Metal to rubber) (design as per requirement)
