Agilent E4419B EPM Series Dual-Channel Power Meter

The E4419B power meter is designed for bench and automatic test equipment (ATE) use.

• True dual-channel power meter - two simultaneous power readings
• Fast measurement speed (up to 100 readings per second, over the GPIB, with E-series sensors)
• Speed improvement of x2 using the 8480 series power sensor (compared to the 437B)
• No range-switching delays with 8480 series sensors, and only one fast-range switching point with E-series sensors
• Code compatibility with 438A power meter
• GPIB and RS232 connector for remote control of all functions
• Frequency range: 9 kHz to 110 GHz, sensor dependent
• Power range: –70 dBm to +44 dBm (100 pW to 25 W), sensor dependent.
• Power sensors: Compatible with all 8480 series and E-series sensors
• Connector type: Type N (f), 50 Ω
