Rohde & Schwarz FSIQ7 Vector Signal Analyzer (VSA)

The Rohde & Schwarz (R&S) FSIQ7 is a high performance Vector Signal Analyzer with a frequency range of 20 Hz to 7 GHz that was designed for the 3G radio generation.

Features and Specifications of the R&S FSIQ7 Analyzer include:

•  FSIQ 7: 20 Hz to 7 GHz
•  Spectrum Analysis with Ultra-wide Dynamic Range for Sophisticated ACPR
•  Measurements NF = 15 dB/TOI = +20 dBm
•  Figure of merit (NF - TOI) = +5 dBm
•  Integrated Vector Signal Analyzer for Universal Analysis of Digital and Analog
•  Modulated Signals BPSK to 16QAM, (G)MSK, AM, FM, PM
•  Vector Signal Analyzer for W-CDMA Symbol Rate up to 6.4 M symbol/s
•  High-speed Synthesizer with 5 ms Sweep Time for FULL SPAN (FSIQ3/7)
•  High Display Update Rate up to 25 sweeps/s
•  Large Colour Display with High Resolution (24 cm/9.5 TFT)
•  Analysis of Frequency, Time, and Modulation Domain in One Box 82 dB
•  ACPR (Adjacent Channel Power Ratio) in 4.096 MHz
•  Integration Bandwidth for Alternate Channel
•  True RMS Detector for Precise and Repeatable Measurements of any Signal

Options:

B4 - Low Phase Noise
B5 - FFT Bandwidths 1 Hz to 1 KHz
B7 - Vector Signal Analyzer
B10 - Tracking Generator
B13 - RF Attenuator 1dB
K11 - GSM Application S/W (BTS)
K21 - EDGE BTS MEASUREMENTS
K31 - 850MHZ GSM BASE STATION TESTS
