Rohde & Schwarz FSEB30 /K10/K11/B4/B5/B7/B15 Spectrum Analyzer

zoom

pre 1 of 1 next

Location: Worldwide - 32750

Date posted: August 12, 2013

Price: Please contact

Ad ID: 108448

Views: 29

Reply by email

​The Rohde & Schwarz FSEB30 is a 20Hz to 7GHz, Spectrum Analyzers. The FSE spectrum analyzers from Rohde & Schwarz have been optimized both for general-purpose measurements and meeting the stringent requirements of testing advanced digital communication systems.

  • Spectrum analysis with ultra-wide dynamic range Noise figure = 18 dB/TOI = 20 dBm typ.
  • Universal analysis of digital and analog modulated signals (option) such as BPSK, QPSK, π/4-DQPSK, 8PSK, QAM, MSK, GMSK, 2FSK, AM, FM, PM
  • High-speed synthesizer 5 ms for full span
  • Refresh rate, quasi-analog 25 sweeps/s
  • Large LC TFT display 24 cm/9.5", active
  • Future-proof modular design Customized solutions through wide variety of options
  • Displayed noise floor –150 dBm (typ.) in 10-Hz bandwidth
  • 3rd-order intercept point +20 dBm typ.
  • 1 dB compression point of RF input +10 dBm
  • Sweep time: Span = 0 Hz - 1 µs to 2500 s in 5% steps; Span ≥10 Hz - 5 ms to 16 000 s in steps ≤10% ;Error limit <1%
  • Sampling rate 50 ns (20 MHz A/D converter)
  • Number of pixels 500
  • AF demodulation types - AM and FM

Options:

  • K10 - GSM Application S/W (Mobile)
  • K11 - GSM Application S/W (BTS)
  • B4 - Low Phase Noise
  • B5 - FFT Filter
  • B7 - Vector Signal Analyzer
  • B15 - Computer Function Capability w/mouse and keyboard



http://www.ebay.com/itm/Rohde-Schwarz-FSEB30-K10-K11-B4-B5-B7-B15-Spectrum-Analyzer-w-Cal-Warranty-/161082635089?pt=LH_DefaultDomain_0&hash=item258145f351
